Multi Caliber Spectrophotometer, Digital Spectro Colorimeter, with Repeatability dE*ab≤0.02 More Than 30 Measurement Parameters

Technical parameter:Measuring structure:D/8,SCI+SCESCI+SCE simultaneous measurement:supportIntegrated physical positioning holes:supportMeasurement repeatability:dE*ab≤0.02Display accuracy:0.01lighting source:Full-band balanced LED light sourceUV light source:caliber:Φ11mm Φ6mm Φ3mmmeasurement standard:Spectral reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB color difference (ΔE*ab, ΔE*cmc, ΔE*94, ΔE*00), whiteness (ASTME313-00, ASTME313 -73, CIE, ISO2470/R457, AATCC, Hunter, TaubeBerger Stensby) yellowness (ASTM D1925, ASTM E313-00, ASTM E313-73) blackness (My, dM), stain fastness, color fastness, Tint (ASTM E313-00) Color density CMYK (A, T, E, M), metamerism index Milm, Munsell, hiding power, strength (dye strength, tinting strength)Light source conditions:A,B,C,D50,D55,D65,D75F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12CWF,U30,U35,DLF,NBF,TL83,TL84,ID50,ID65,LED-B1,LED-B2,LED-B3,LED-B4LED-B5,LED-BH1,LED-RGB1,LED-V1,LED-V2Spectral method:High-precision nano spectroscopic devicesensor:Silicon photodiode array dual 16 groupsWavelength interval:10nmWavelength range:400-700nmReflectivity measurement range:0-200%Reflectance resolution:0.01%measure time:about 1sinterface:USB, Bluetoothlanguage:Simplified Chinese, Englishstorage:Instrument: 10,000 items; APP: Mass storage

• Nearly 40 evaluation light sources such as A, B, C, D50, D55, D65 are available, including almost all color measurement indicators and light source types in the industry.
• Horizontal spectrophotometer, High repeatability accuracy: dE*ab≤0.02; Horizontal press measurement, physical positioning observation window; More than 30 chroma indicators and 40 evaluation.
• Horizontal press measurement, physical positioning observation window spectrophotometer with low center of gravity horizontal design, can be stable measurement of the surface under test.
• Ultra-high repeatability accuracy：spectrophotometer adopts high-precision nano-spectrophotometer, which makes the repeatability accuracy of the instrument reach the level dE*ab≤0.02.
• More than 30 measurement parameters and nearly 40 evaluation light sources DS60 series spectrophotometer provides spectral reflectance, CIE-Lab, CIE-LCh, ΔE*ab, covering power, whiteness, yellowness and other 30+ measurement indexes.
